Symptom:
*PCI BUS COMMUNICATION FAILURE
POSSIBLE CAUSES
WIRING HARNESS INTERMITTENT
OPEN PCI BUS CIRCUIT AT THE DATA LINK CONNECTOR (DLC)
PCI BUS CIRCUIT SHORTED TO VOLTAGE
MODULE SHORT TO VOLTAGE
PCI BUS CIRCUIT SHORTED TO GROUND
MODULE SHORT TO GROUND
TEST ACTION APPLICABILITY
1 Note: Determine which modules this vehicle is equipped with before begin-
ning.
Note: When attempting to communicate with any of the modules on this
vehicle, the DRB will display 1 of 2 different communication errors: a NO
RESPONSE message or a BUS +/- SIGNALS OPEN message.
Turn the ignition on.
Using the DRB, attempt to communicate with the following control modules:
Airbag Control Module
SKIM (SENTRY KEY IMMOBILIZER)
MIC (INSTRUMENT CLUSTER)
Was the DRBIIIt able to communicate with one or more Module(s)?
All
Yes → Go To 2
No → Go To 3
2 Turn the ignition off.
Note: Visually inspect the related wiring harness. Look for any chafed,
pierced, pinched, or partially broken wires.
Note: Visually inspect the related wire harness connectors. Look for broken,
bent, pushed out, or corroded terminals.
Note: If the DRB can not communicate with a single module, refer to the
category list for the related symptom.
Were any problems found?
All
Yes → Repair wiring harness/connectors as necessary.
Perform BODY VERIFICATION TEST - VER 1.
No → Test Complete.
124
COMMUNICATION
