Symptom List:
LEFT FRONT SENSOR CIRCUIT FAILURE
LEFT REAR SENSOR CIRCUIT FAILURE
RIGHT FRONT SENSOR CIRCUIT FAILURE
RIGHT REAR SENSOR CIRCUIT FAILURE
Test Note: All symptoms listed above are diagnosed using the same tests.
The title for the tests will be LEFT FRONT SENSOR CIRCUIT
FAILURE.
When Monitored and Set Condition:
LEFT FRONT SENSOR CIRCUIT FAILURE
When Monitored: Ignition on. The CAB monitors the wheel speed circuit continuously.
Set Condition: If the CAB detects an open or shorted wheel speed sensor circuit, the
Diagnostic Trouble Code (DTC) will set.
LEFT REAR SENSOR CIRCUIT FAILURE
When Monitored: Ignition on. The CAB monitors the wheel speed circuit continuously.
Set Condition: If the CAB detects an open or shorted wheel speed sensor circuit, the
Diagnostic Trouble Code (DTC) will set.
RIGHT FRONT SENSOR CIRCUIT FAILURE
When Monitored: Ignition on. The CAB monitors the wheel speed circuit continuously.
Set Condition: If the CAB detects an open or shorted wheel speed sensor circuit, the
Diagnostic Trouble Code (DTC) will set.
RIGHT REAR SENSOR CIRCUIT FAILURE
When Monitored: Ignition on. The CAB monitors the wheel speed circuit continuously.
Set Condition: If the CAB detects an open or shorted wheel speed sensor circuit, the
Diagnostic Trouble Code (DTC) will set.
POSSIBLE CAUSES
INTERMITTENT CONDITION
WHEEL SPEED SENSOR OR CONNECTOR DAMAGE
WHEEL SPEED SENSOR SIGNAL CIRCUIT FAULT
WHEEL SPEED SENSOR 12 VOLT SUPPLY CIRCUIT SHORT TO GROUND
WHEEL SPEED SENSOR 12 VOLT SUPPLY CIRCUIT OPEN
WHEEL SPEED SENSOR SIGNAL CIRCUIT SHORT TO GROUND
WHEEL SPEED SENSOR SIGNAL CIRCUIT OPEN
16
BRAKES (CAB)
