Symptom List:
ABS INDICATOR CIRCUIT OPEN
AIRBAG INDICATOR CIRCUIT OPEN
Test Note: All symptoms listed above are diagnosed using the same tests.
The title for the tests will be ABS INDICATOR CIRCUIT
OPEN.
When Monitored and Set Condition:
ABS INDICATOR CIRCUIT OPEN
When Monitored: With the ignition on and requested to turn on by the ABS module.
Set Condition: The Instrument Cluster detects an open during the internal test on the
indicator.
AIRBAG INDICATOR CIRCUIT OPEN
When Monitored: With the ignition on and requested to turn on by the ACM.
Set Condition: The Instrument Cluster detects an open during the internal test on the
indicator.
POSSIBLE CAUSES
INSTRUMENT CLUSTER
TEST ACTION APPLICABILITY
1 NOTE: The Instrument Cluster performs internal tests on the ABS and
Airbag indicators each ignition cycle. These indicator LEDs are not replace-
able.
With the DRBIIIt, erase DTCs.
Cycle the ignition and wait approximately 1 minute.
Did the ABS or Airbag indicator DTC reset?
All
Yes → Replace the Instrument Cluster in accordance with the Service
Information.
Perform BODY VERIFICATION TEST - VER 1.
No → Test Complete.
