TEST ACTION APPLICABILITY
5 Remove and test Fuse 15 from the Fuse Block.
Is the Fuse open?
All
Yes → Go To 6
No → Repair the open Fused B+ Circuit between the Multifunction
Switch and the Fuse Block.
Perform BODY VERIFICATION TEST - VER 1.
6 Remove Circuit Breaker 2 from the Fuse Block.
Measure resistance of the Fused B+ circuit in the fuse connector to ground.
Is the resistance below 5.0 ohms?
All
Yes → Repair the Fused B+ Circuit for a short to ground condition.
Perform BODY VERIFICATION TEST - VER 1.
No → Replace the Circuit Breaker and retest the system.
Perform BODY VERIFICATION TEST - VER 1.
138
EXTERIOR LIGHTING
*LOW BEAM HEADLAMPS WILL NOT TRN ON — Continued
To Next Page
