FUSES (PDC)
FUSE
NO.
AMPS FUSED CIRCUIT FUNCTION
1- - -
2- - -
3 40A A3 12RD/WT FUSED B(+)
4 40A A2 12PK/BK FUSED B(+)
5 30A A20 12RD/DB (ABS) FUSED B(+)
6 30A A16 14GY (2.0L) FUSED B(+)
6 30A A16 12GY (2.4L TURBO) FUSED B(+)
7- - -
8 40A A10 12RD/DG (ABS) FUSED B(+)
9 30A A1 14RD FUSED B(+)
10 40A A4 10BK/RD (2.0L) FUSED B(+)
10 40A A4 10BK/PK (2.4L TURBO) FUSED B(+)
11 - - -
12 - - -
13 20A M11 16PK/LB FUSED B(+)
14 20A F1 16DB FUSED B(+)
15 15A A15 18WT (2.0L) FUSED B(+)
15 15A A15 18RD/PK (2.4L TURBO) FUSED B(+)
16 15A A200 18RD/BR (2.0L RT) FUSED B(+)
17 20A A30 16RD/WT (2.0L EATX) FUSED B(+)
18 10A F62 20RD (2.0L) FUSED B(+)
18 10A F62 20RD (2.0L) FUSED B(+)
18 15A F62 18RD (2.4L TURBO) FUSED B(+)
18 15A F62 18RD (2.4L TURBO) FUSED B(+)
19 - - -
20 25A F61 16WT/OR (EXPORT) FUSED B(+)
21 20A A14 16RD/WT FUSED B(+)
22 10A A17 20RD/BK FUSED B(+)
23 15A F32 18PK/DB FUSED B(+)
TRANSMISSION CONTROL RELAY
CAV CIRCUIT FUNCTION
44 Z1 20BK GROUND
45 A30 16RD/WT FUSED B(+)
46 T16 16RD TRANSMISSION CONTROL RELAY OUTPUT
47 - -
48 T15 20LG TRANSMISSION CONTROL RELAY CONTROL
C
O
N
N
E
C
T
O
R
P
I
N
O
U
T
S
190
CONNECTOR PINOUTS
