FUSES (FB RHD)
FUSE
NO.
AMPS FUSED CIRCUIT FUNCTION
1 10A L6 20RD/WT FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
1 10A L6 20RD/WT FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
2 20A V6 16DB FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
2 20A V6 16DB FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
3 20A F10 18YL/RD FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
3 20A X12 18RD/WT FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
4 15A M1 18PK FUSED B(+)
5 15A L3 14RD/OR DIMMER SWITCH HIGH BEAM OUTPUT
6 10A F20 20WT FUSED IGNITION SWITCH OUTPUT (RUN)
7 20A C1 14DG FUSED IGNITION SWITCH OUTPUT (RUN)
8 10A F25 20TN/LG FUSED IGNITION SWITCH OUTPUT (RUN)
9 10A A81 20DG/RD (AUTOSTICK) FUSED B(+)
10 10A G5 20DB/WT FUSED IGNITION SWITCH OUTPUT (RUN-START)
11 15A F12 18DB/PK FUSED IGNITION SWITCH OUTPUT (RUN-START)
12 10A F15 20DG/WT FUSED IGNITION SWITCH OUTPUT (RUN-START)
13 20A A120 16RD/LG FUSED B(+)
14 20A F35 18RD FUSED B(+)
15 15A F33 18PK/RD FUSED B(+)
16 25A F3 12LB/OR FUSED B(+)
17 10A L43 14VT FUSED LEFT LOW BEAM OUTPUT
18 10A L44 14VT/RD FUSED RIGHT LOW BEAM OUTPUT
19 - - -
20 10A C16 20LB/YL FUSED REAR WINDOW DEFOGGER SWITCH OUTPUT
20 10A C16 20LB/YL FUSED REAR WINDOW DEFOGGER SWITCH OUTPUT
