Symptom:
*HIGH BEAM HEADLAMPS WILL NOT TURN OFF
POSSIBLE CAUSES
DIMMER SWITCH HIGH BEAM OUTPUT CIRCUIT SHORT TO VOLTAGE
INSTRUMENT CLUSTER
MULTIFUNCTION SWITCH
TEST ACTION APPLICABILITY
1 Remove Circuit Breaker 2 from the Fuse Block.
Do the High Beam Headlamps turn off?
All
Yes → Go To 2
No → Repair the Dimmer Switch High Beam Output Circuit for a short
to voltage condition.
Perform BODY VERIFICATION TEST - VER 1.
2 Disconnect the Instrument Cluster connector.
Disconnect the Multifunction Switch connector.
Measure resistance of the Dimmer Switch High Beam Output Circuit to ground.
Is the resistance below 5.0 ohms?
All
Yes → Replace the Instrument Cluster.
Perform BODY VERIFICATION TEST - VER 1.
No → Replace the Multifunction Switch.
Perform BODY VERIFICATION TEST - VER 1.
135
EXTERIOR LIGHTING
