Symptom:
PUMP CIRCUIT FAILURE
When Monitored and Set Condition:
PUMP CIRCUIT FAILURE
When Monitored: Ignition on. The CAB commands the pump on at 20 km/h (12 mph) to
check its operation, if the brake switch is not applied. If the brake is applied, the test will
run at 40 km/h (25 mph).
Set Condition: The DTC is stored when the CAB detects: 1) Improper voltage decay after
the pump was turned off. 2) Pump not energized by the CAB, but voltage is present for 3.5
seconds. 3) Pump is turned on by the CAB, but without sufficient voltage to operate it.
POSSIBLE CAUSES
CAB - PUMP MOTOR RUNNING CONTINUOUSLY
ABS PUMP FUSE
ABS PUMP MOTOR INTERMITTENT DTC
DAMAGED CAB/CAB HARNESS CONNECTOR
ABS PUMP FUSED B(+) CIRCUIT INTERMITTENT SHORT TO GROUND
ABS PUMP FUSED B(+) CIRCUIT SHORT TO GROUND
CAB - INTERNAL FAULT
ABS PUMP MOTOR INOPERATIVE
ABS PUMP MOTOR OPEN
ABS PUMP MOTOR B(+) CIRCUIT OPEN
ABS PUMP MOTOR GROUND CIRCUIT OPEN
CAB - INTERNAL FAULT
TEST ACTION APPLICABILITY
1 Turn the ignition off.
Turn the ignition on.
Monitor the ABS Pump Motor for continuous operation.
NOTE: The CAB must sense ALL wheels at 25 km/h (15 mph) before it will
extinguish the ABS indicators.
Is the ABS Pump Motor running continuously?
All
Yes → Replace the Controller Antilock Brake in accordance with the
Service Information.
Perform ABS VERIFICATION TEST - VER 1.
No → Go To 2
24
BRAKES (CAB)
