Symptom:
*AIRBAG INDICATOR ON WITHOUT ACM TROUBLE CODES
POSSIBLE CAUSES
INSTRUMENT CLUSTER PROBLEMS
ACM, INDICATOR ON NO CODES
TEST ACTION APPLICABILITY
1 Turn the ignition on.
Make surethat allactive DTC’s have been repairedbefore performingthis procedure.
WARNING: TO AVOID PERSONAL INJURY OR DEATH, TURN IGNITION
OFF, DISCONNECT THE BATTERY AND WAIT TWO MINUTES BEFORE
PROCEEDING.
Does the DRBIIIt show LAMP REQ BY ACM: ON?
All
Yes → Go To 2
No → Refer to INSTRUMENT CLUSTER CATEGORY symptom list for
problems related to Instrument Cluster.
Perform AIRBAG VERIFICATION TEST - VER 1.
NOTE: When reconnecting Airbag system components, the ignition must be
turned off and the battery must be disconnected.
2 WARNING: TO AVOID PERSONAL INJURY OR DEATH, TURN IGNITION
OFF, DISCONNECT THE BATTERY AND WAIT TWO MINUTES BEFORE
PROCEEDING.
WARNING: IF THE AIRBAG CONTROL MODULE IS DROPPED AT ANY
TIME, IT MUST BE REPLACED. FAILURE TO TAKE THE PROPER PRE-
CAUTIONS COULD RESULT IN ACCIDENTAL AIRBAG DEPLOYMENT
AND PERSONAL INJURY OR DEATH.
If there are no possible causes remaining, view repair.
All
Repair
Replace theAirbag Control Module in accordance with the Service
information.
Perform AIRBAG VERIFICATION TEST - VER 1.
82
AIRBAG
