Symptom:
PASSENGER SQUIB 1 CIRCUIT SHORT
When Monitored and Set Condition:
PASSENGER SQUIB 1 CIRCUIT SHORT
When Monitored: When the ignition is on, the ACM monitors the resistance of the
Passenger Squib 1 circuits.
Set Condition: The ACM has detected low resistance in the Passenger Squib 1 circuits.
POSSIBLE CAUSES
PASSENGER AIRBAG CIRCUIT SHORT
PASSENGER SQUIB 1 LINE 1 SHORT TO LINE 2
ACM, PASSENGER SQUIB 1 CIRCUIT SHORT
STORED CODE OR INTERMITTENT CONDITION
ACTIVE CODE PRESENT
TEST ACTION APPLICABILITY
1 NOTE: Ensure that the battery is fully charged.
Turn the ignition on.
NOTE: For the purpose of this test, the AECM and ORC modules will be
referred to as an ACM.
SELECT ACTIVE or STORED DTC:
All
ACM - ACTIVE DTC
Go To 2
ACM - STORED DTC
Go To 4
NOTE: When reconnecting Airbag system components, the ignition must be
turned off and the battery must be disconnected.
61
AIRBAG
