Symptom:
EATX MISMATCH
When Monitored and Set Condition:
EATX MISMATCH
When Monitored: With the ignition on.
Set Condition: The Instrument Cluster detects that the configuration programmed by the
plant does not equal the configuration of the cluster.
POSSIBLE CAUSES
EATX BUS MESSAGE DTC PRESENT
INSTRUMENT CLUSTER CONFIGURATION INCORRECT
INSTRUMENT CLUSTER
TEST ACTION APPLICABILITY
1 With the DRBIIIt, read DTCs.
Does the DRBIIIt display 9EATX Bus Message Not Received9?
All
Yes → Refer to Communication for the related symptom.
No → Go To 2
2 With the DRBIIIt in Cluster Type, ensure that the Instrument Cluster is correctly
configured.
Is the Instrument Cluster configured correctly?
All
Yes → Replace the Instrument Cluster in accordance with the Service
Information.
Perform BODY VERIFICATION TEST - VER 1.
No → With the DRBIIIt, configure the Instrument Cluster.
Perform BODY VERIFICATION TEST - VER 1.
145
INSTRUMENT CLUSTER
