Symptom:
P0630-VIN NOT PROGRAMMED IN PCM
When Monitored and Set Condition:
P0630-VIN NOT PROGRAMMED IN PCM
When Monitored: Ignition on.
Set Condition: The VIN has not been programmed into the PCM.
POSSIBLE CAUSES
PROGRAMMING VIN INTO PCM
VERIFY PCM PROGRAMMING
PCM
TEST ACTION APPLICABILITY
1 Ignition on, engine not running.
With the DRBIIIt, erase DTCs.
Using the DRBIIIt, program VIN into the PCM.
Start the engine.
NOTE: If the engine will not start, crank the engine over for 15 seconds.
Crank at least 2 times with the ignition switch returning to the off position
each time.
Allow the engine to reach normal operating temperature.
With the DRBIIIt, read DTCs.
Does the DTC reset?
All
Yes → Go To 2
No → The VIN has been successfully programmed into the PCM. Test is
complete.
Perform POWERTRAIN VERIFICATION TEST VER - 1.
2 NOTE: The ignition switch must be left in the off position for a minimum of
10 seconds.
Cycle the ignition switch to the off position and then back to run.
Attempt to program the PCM with the applicable information.
Start the vehicle and allow it to reach normal operating temperatures.
With the DRBIIIt, read DTCs.
Does the DTC reset?
All
Yes → Replace and program the Powertrain Control Module in accor-
dance with the Service Information.
Perform POWERTRAIN VERIFICATION TEST VER - 1.
No → The VIN has been successfully programmed into the PCM. Test is
complete.
Perform POWERTRAIN VERIFICATION TEST VER - 1.
230
DRIVEABILITY - NGC
