Symptom:
*HIGH BEAM HEADLAMPS WILL NOT TRN ON
POSSIBLE CAUSES
OPEN FUSED B+
DIMMER SWITCH LOW BEAM OUTPUT CIRCUIT SHORT TO GROUND
DIMMER SWITCH HIGH BEAM OUTPUT CIRCUIT SHORT TO GROUND
OPEN FUSE
DIMMER SWITCH LOW BEAM OUTPUT CIRCUIT OPEN
INSTRUMENT CLUSTER
MULTIFUNCTION SWITCH
TEST ACTION APPLICABILITY
1 Remove Circuit Breaker 2 from the Fuse Block.
Measure voltage of the Fused B+ circuit at the Circuit Breaker connector.
Is the voltage above 10.0 volts?
All
Yes → Go To 2
No → Repair the open Fused B+ circuit from Fuse Block fuse 15.
Perform BODY VERIFICATION TEST - VER 1.
2 Check fuse 15 in the Fuse Block.
Is fuse 15 open?
All
Yes → Go To 3
No → Go To 5
3 Remove fuse 15 from the Fuse Block.
Disconnect the Multifunction Switch connector.
Measure resistance of the Dimmer Switch Low Beam Output Circuit to ground.
Is the resistance below 5.0 ohms?
All
Yes → Repair the Dimmer Switch Low Beam Output Circuit for a short
to ground condition.
Perform BODY VERIFICATION TEST - VER 1.
No → Go To 4
4 Remove Circuit Breaker 2 from the Fuse Block.
Disconnect the Multifunction Switch connector.
Measure resistance of the Dimmer Switch High Beam Output Circuit and ground.
Is the resistance below 5.0 ohms?
All
Yes → Repair the Dimmer Switch High Beam Output Circuit for a short
to ground condition.
Perform BODY VERIFICATION TEST - VER 1.
No → Go To 5
133
EXTERIOR LIGHTING
