Symptom:
SEAT SQUIB SHORT TO GROUND
When Monitored and Set Condition:
SEAT SQUIB SHORT TO GROUND
When Monitored: When the ignition is on, the SIACM monitors the resistance of the Seat
Squib circuits.
Set Condition: When the SIACM detects a short to ground on the Seat Squib circuits.
POSSIBLE CAUSES
SEAT AIRBAG SHORT TO GROUND
SEAT SQUIB LINE 1 OR LINE 2 SHORTED TO GROUND
SIACM, SEAT SQUIB SHORT TO GROUND
STORED CODE OR INTERMITTENT CONDITION
ACTIVE CODE PRESENT
TEST ACTION APPLICABILITY
1 Ensure the battery is fully charged.
Turn the ignition on.
NOTE: For the purpose of this test, the AECM and ORC modules will be
referred to as an ACM.
SELECT ONE:
All
LEFT SIACM - ACTIVE DTC
Go To 2
LEFT SIACM - STORED DTC
Go To 4
RIGHT SIACM - ACTIVE DTC
Go To 2
RIGHT SI ACM - STORED DTC
Go To 4
NOTE: When reconnecting Airbag system components, the ignition must be
turned off and the battery must be disconnected.
79
AIRBAG
