Symptom:
P0498-NVLD CANISTER VENT VALVE SOLENOID CIRCUIT LOW
When Monitored and Set Condition:
P0498-NVLD CANISTER VENT VALVE SOLENOID CIRCUIT LOW
When Monitored: Engine Running.
Set Condition: The PCM detects a short in the NVLD Canister vent solenoid circuits. One
trip Fault.
POSSIBLE CAUSES
GOOD TRIP EQUAL TO ZERO
NVLD SOLENOID
(K106) NVLD SOLENOID CONTROL CIRCUIT SHORT TO GROUND
PCM
TEST ACTION APPLICABILITY
1 Ignition on, engine not running.
With the DRBIIIt, read DTCs and record the related Freeze Frame data.
Is the Good Trip Counter displayed and equal to zero?
All
Yes → Go To 2
No → Refer to the INTERMITTENT CONDITION symptom in the
Driveability category.
Perform POWERTRAIN VERIFICATION TEST VER-5-NGC.
2 Turn the ignition off.
Disconnect the NVLD electrical harness connector.
Measure the resistance of the NVLD Solenoid coil.
Is the resistance between 7.5 to 8.5 ohms?
All
Yes → Go To 3
No → Replace the NVLD Assembly.
Perform POWERTRAIN VERIFICATION TEST VER-5-NGC.
3 Turn the ignition off.
Disconnect the NVLD electrical harness connector.
Disconnect the PCM harness connector.
Measure the resistance between ground and the (K106) NVLD Sol Control circuit at
the NVLD electrical harness connector.
Is the resistance below 5.0 ohms?
All
Yes → Repair the short to ground in the (K106) NVLD Solenoid Control
circuit.
Perform POWERTRAIN VERIFICATION TEST VER-5-NGC.
No → NOTE: Before continuing, check the PCM harness connector
terminals for corrosion, damage or terminal push out. Repair as
necessary. Replace and program the Powertrain Control Module
in accordance with the Service Information.
Perform POWERTRAIN VERIFICATION TEST VER-5-NGC.
184
DRIVEABILITY - NGC
