Symptom:
VALVE POWER FEED FAILURE
When Monitored and Set Condition:
VALVE POWER FEED FAILURE
When Monitored: Ignition on. The CAB monitors its internal microprocessors for correct
operation.
Set Condition: If the CAB detects an internal fault, the DTC is set.
POSSIBLE CAUSES
INTERMITTENT DTC
ABS VALVE FUSE
ABS VALVE FUSED B(+) SUPPLY CIRCUIT OPEN
ABS VALVE FUSED B(+) CIRCUIT OPEN
ABS VALVE FUSED B(+) CIRCUIT INTERMITTENT SHORT TO GROUND
ABS VALVE FUSED B(+) CIRCUIT SHORT TO GROUND
DAMAGED CAB/CAB HARNESS CONNECTOR
CAB - GROUND CIRCUIT OPEN
CAB - INTERNAL FAULT
TEST ACTION APPLICABILITY
1 Turn the ignition on.
With the DRBIIIt, read DTC’s.
With the DRBIIIt, erase DTC’s.
Turn the ignition off.
Turn the ignition on.
With the DRBIIIt, read DTC’s.
Does the DRBIIIt display VALVE POWER FEED FAILURE?
All
Yes → Go To 2
No → Go To 10
2 Turn the ignition off.
Remove and Inspect the ABS Valve fuse.
Is the ABS Valve fuse open?
All
Yes → Go To 3
No → Go To 6
33
BRAKES (CAB)
