Symptom:
NO AIRBAG MESSAGES RECEIVED
When Monitored and Set Condition:
NO AIRBAG MESSAGES RECEIVED
When Monitored: With the ignition on or in the run position.
Set Condition: The RKE Module does not receive any airbag messages for 12 seconds.
POSSIBLE CAUSES
ATTEMPT TO COMMUNICATE WITH THE ACM
RKE MODULE
TEST ACTION APPLICABILITY
1 Turn the ignition on.
With the DRB, attempt to communicate with the ACM.
Was the DRB able to I/D or communicate with the ACM?
All
Yes → Go To 2
No → Refer to the Communication category for the related symptom(s).
Perform BODY VERIFICATION TEST - VER 1.
2 With the DRB, erase DTC’s.
Turn the ignition on and wait approximately 1 minute.
With the DRB, read DTC’s.
Did this DTC reset?
All
Yes → Replace the Remote Keyless Entry Module.
Perform BODY VERIFICATION TEST - VER 1.
No → Test Complete.
187
POWER DOOR LOCKS/RKE
