Symptom:
*FUEL GAUGE INACCURATE
POSSIBLE CAUSES
DTC PRESENT
FUEL LEVEL SENSOR
INTERMITTENT CONDITION
INSTRUMENT CLUSTER
TEST ACTION APPLICABILITY
1 Turn the ignition on.
With the DRBIIIt, read DTCs.
Does the DRBIIIt display Fuel Level Sensor Open or Fuel Level Sensor Short?
All
Yes → Refer to Fuel Level Sensor Open or Fuel Level Sensor Short for
the related symptom(s).
No → Go To 2
2 Perform the Instrument Cluster Self Test.
Turn the ignition off.
Press and hold the Trip Reset button.
Turn the ignition on.
Observe the Fuel Gauge during the Self Test.
The FuelGauge pointershould pause at each ofthese followingpositions: E, 1/2, Full.
Did the Fuel Gauge perform the Self Test properly?
All
Yes → Go To 3
No → Replace the Instrument Cluster in accordance with the Service
Information.
Perform BODY VERIFICATION TEST - VER 1.
162
INSTRUMENT CLUSTER
