TEST ACTION APPLICABILITY
3 Turn the ignition off.
Remove the Fuel Pump Module from the Fuel Tank.
NOTE: Inspect for physical obstructions in the Fuel Tank. Inspect the Fuel
Level Sensor for bent or damaged parts.
Measure the resistance of the Fuel Level Sensor while moving the float arm through
the complete range of motion.
The Fuel Level Sensor should measure the following resistances:
E = 184 - 204 ohms
1/4 = 360 - 410 ohms
1/2 = 565 - 585 ohms
3/4 = 741 - 791 ohms
Full = 947 - 967 ohms
NOTE: The Fuel Level Sensor should read resistance through the full range
of float arm motion.
Does the Fuel Level Sensor read the proper resistance values through the full range
of motion?
All
Yes → The condition is not present at this time. Monitor DRBIIIt
parameters while wiggling the related wire harness. Refer to any
Technical Service Bulletins (TSB) that may apply. Visually in-
spect the related wiring harness and connector terminals.
No → Replace the Fuel Level Sensor in accordance with the Service
Information.
Perform BODY VERIFICATION TEST - VER 1.
163
INSTRUMENT CLUSTER
*FUEL GAUGE INACCURATE — Continued
To Next Page
