Symptom:
P0172-FUEL SYSTEM 1/1 RICH
When Monitored and Set Condition:
P0172-FUEL SYSTEM 1/1 RICH
When Monitored: With the engine running in closed loop mode, the ambient/battery
temperature above (-7°C)20°F and altitude below 8500 ft.
Set Condition: If the PCM multiplies short term compensation by long term adaptive as
well as a purge fuel multiplier and the result is below a certain value for 30 seconds over
two trips, a freeze frame is stored, the MIL illuminates and a trouble code is stored.
POSSIBLE CAUSES
GOOD TRIP EQUAL TO ZERO
O2 SENSOR HEATER OPERATION
O2 SENSOR
EVAP PURGE SOLENOID OPERATION
O2 SIGNAL CIRCUIT
O2 RETURN CIRCUIT
MAP SENSOR OPERATION
ECT SENSOR OPERATION
ENGINE MECHANICAL PROBLEM
FUEL FILTER/PRESSURE REGULATOR
PCM
TEST ACTION APPLICABILITY
1 NOTE: Check for contaminants that may have damaged the O2 Sensor:
contaminated fuel, unapproved silicone, oil and coolant.
Ignition on, engine not running.
With the DRBIIIt, read DTCs and record the related Freeze Frame data.
Is the Good Trip Counter displayed and equal to zero?
All
Yes → Go To 2
No → Refer to the INTERMITTENT CONDITION symptom in the
Driveability category.
Perform POWERTRAIN VERIFICATION TEST VER-5-NGC.
108
DRIVEABILITY - NGC
