TEST ACTION APPLICABILITY
12 Turn the ignition off.
Warning: The fuel system is under a constant pressure (even with the engine
off). Before testing or servicing any fuel system hose, fitting or line, the fuel
system pressure must be released.
Raise vehicle on hoist, and disconnect the fuel pressure line at the fuel pump module.
Install special 5/16 fuel line adapter tool #6539 between the disconnected fuel line
and the fuel pump module.
Attach a fuel pressure test gauge to the T fitting on the tool #6539
Turn the ignition on.
With the DRBIIIt, actuate the ASD Fuel System test and observe the fuel pressure
gauge.
NOTE: Fuel pressure specification is 400 KPa +/- 34 KPa (58 psi +/- 5 psi).
Is the fuel pressure within specification?
All
Yes → Repair or replace fuel supply line as necessary.
Perform POWERTRAIN VERIFICATION TEST VER-5-NGC.
No → Go To 13
Caution: Stop All Actuations.
13 Turn the ignition off.
Warning: The fuel system is under a constant pressure (even with the engine
off). Before testing or servicing any fuel system hose,fitting or line, the fuel
system pressure must be released.
Remove the Fuel Pump Module and inspect the Fuel Inlet Strainer.
Is the Fuel Inlet Strainer plugged?
All
Yes → Replace the Fuel Pump Inlet Strainer.
Perform POWERTRAIN VERIFICATION TEST VER-5-NGC.
No → Go To 14
14 If there are no possible causes remaining, view repair. All
Repair
Replace the Fuel Pump Module.
Perform POWERTRAIN VERIFICATION TEST VER-5-NGC.
107
DRIVEABILITY - NGC
P0171-FUEL SYSTEM 1/1 LEAN — Continued
To Next Page
