Symptom:
COMPASS/TEMPERATURE MIRROR INTERNAL FAILURE
POSSIBLE CAUSES
COMPASS/TEMP MIRROR
TEST ACTION APPLICABILITY
1 Perform the Compass/Temp Mirror Self-Check.
Turn the ignition on.
Press and hold the left lamp button for 20-25 seconds.
The display will illuminate each of the VF segments:
CAL
ZONE
N, NE, E, SE, S, SW, W, NW
The numerals 0 through 9
C° and F°
The Compass/Temp Mirror will test the memory and the compass.
Press the left lamp button or cycle the ignition to exit the Self-Check.
The Compass/Temp Mirror will display a 9P9 for Pass or an 9F9 for Fail.
Did the Compass/Temp Mirror display an 9F9 after the Self-Check?
All
Yes → Replace the Compass/Temp Mirror in accordance with the Service
Information.
Perform BODY VERIFICATION TEST - VER 1.
No → Test Complete.
127
COMPASS/MINI-TRIP COMPUTER
