Symptom:
*RKE INOPERATIVE
POSSIBLE CAUSES
TEST TRANSMITTER WITH TESTER
RKE TRANSMITTER NOT PROGRAMMED
TEST RKE TRANSMITTER
RKE TRANSMITTER - INOPERATIVE
RKE MODULE
RKE MODULE - RECEIVER INOPERABLE
TEST ACTION APPLICABILITY
1 NOTE: Ensure the RKE module is configured for RKE and the M1 (IOD) fuse
is installed.
Note: Ensure the voltage of each battery is greater than 3.0 volts before
proceeding.
Do you have access to the Miller Tool 99001 RF DETECTOR9??
All
Yes → Go To 2
No → Go To 4
2 Using the 9001 RF Detector, follow the instructions on the back of the tester and test
the transmitter several times.
Does the signal strength measure 9STRONG9?
All
Yes → Go To 3
No → Replace the transmitter.
Perform BODY VERIFICATION TEST - VER 1.
3 Turn the ignition on
Place transmission in the Park position.
Ensure Vehicle Theft Security System (if equipped) is in Disarm Mode.
With the DRBIIIt, select Theft Alarm, VTSS, MISCELLANEOUS, then PROGRAM
RKE. Follow the instructions on the screen.
Exit PROGRAM RKE.
Activate the Door Locks using the RKE Transmitter.
Did the door locks respond properly to the RKE transmitter commands?
All
Yes → Repair complete.
Perform BODY VERIFICATION TEST - VER 1.
No → Replace the Remote Keyless Entry Module and reprogram all
transmitters used with this vehicle.
Perform BODY VERIFICATION TEST - VER 1.
211
POWER DOOR LOCKS/RKE
