Symptom:
*HIGH BEAM INDICATOR INOPERATIVE
POSSIBLE CAUSES
HIGH BEAM INDICATOR CIRCUIT OPEN
HIGH BEAM INDICATOR BULB
INSTRUMENT CLUSTER
TEST ACTION APPLICABILITY
1 NOTE: Ensure that the High Beam headlamps operate properly before
proceeding with this test.
Turn the ignition off.
Disconnect the Instrument Cluster harness connector.
Turn on the headlamps and actuate the High Beams.
Using a12-volt test lightconnected to ground,check the High Beam Indicator circuit.
Does the test light illuminate brightly?
All
Yes → Go To 2
No → Repair the High Beam Indicator circuit for an open.
Perform BODY VERIFICATION TEST - VER 1.
2 Turn the ignition off.
Disconnect the Instrument Cluster harness connector.
Remove and inspect the High Beam Indicator bulb.
Is the bulb open?
All
Yes → Replace the High Beam Indicator bulb in accordance with the
Service Information.
Perform BODY VERIFICATION TEST - VER 1.
No → Replace the Instrument Cluster in accordance with the Service
Information.
Perform BODY VERIFICATION TEST - VER 1.
164
INSTRUMENT CLUSTER
