Symptom:
CONFIGURATION ERROR
When Monitored and Set Condition:
CONFIGURATION ERROR
When Monitored: With ignition on the Side Impact Airbag Control Module monitors the
unused squib terminals for the a valid squib circuit resistance.
Set Condition: When the SIACM detects a valid squib circuit resistance across the
unused terminals.
POSSIBLE CAUSES
SELECT MODULE REPORTING DTC
MISS WIRED LEFT SIACM CONNECTOR
MISS WIRED RIGHT SIACM CONNECTOR
LEFT SIDE IMPACT AIRBAG CONTROL MODULE - LSIACM
RIGHT SIDE IMPACT AIRBAG CONTROL MODULE - LSIACM
STORED CODE OR INTERMITTENT CONDITION
ACTIVE CODE PRESENT
TEST ACTION APPLICABILITY
1 Turn the ignition on.
NOTE: Ensure that the battery is fully charged.
NOTE: For the purpose of this test, the AECM and ORC modules will be
referred to as an ACM.
SELECT ONE:
All
LEFT SIACM - ACTIVE DTC
Go To 2
LEFT SIACM - STORED DTC
Go To 4
RIGHT SIACM - ACTIVE DTC
Go To 3
RIGHT SIACM - STORED DTC
Go To 4
NOTE: When reconnecting Airbag system components, the ignition must be
turned off and the battery must be disconnected.
