TEST ACTION APPLICABILITY
2 WARNING: TURN IGNITION OFF, DISCONNECT THE BATTERY AND WAIT
TWO MINUTES BEFORE PROCEEDING.
Disconnect the Left SIACM connector.
NOTE: Check connectors - Clean and repair as necessary.
Using the wiring diagram/schematic as a guide, inspect the Left SIACM connector
wiring.
Is the connector correctly wired?
All
Yes → Replace the Left Side Impact Airbag Control Module in accor-
dance with Service Instructions. WARNING: IF THE SIDE IM-
PACT AIRBAG CONTROL MODULE IS DROPPED AT ANY
TIME, IT MUST BE REPLACED.
Perform AIRBAG VERIFICATION TEST - VER 1.
No → Rewire the Left Side Impact Airbag Control Module connector.
Perform AIRBAG VERIFICATION TEST - VER 1.
3 WARNING: TURN IGNITION OFF, DISCONNECT THE BATTERY AND WAIT
TWO MINUTES BEFORE PROCEEDING.
Disconnect the Right SIACM connector.
NOTE: Check connectors - Clean and repair as necessary.
Using the wiring diagram/schematic as a guide, inspect the Right SIACM connector
wiring.
Is the connector correctly wired?
All
Yes → Replace the Right Side Impact Airbag Control Module in accor-
dance with Service Instructions. WARNING: IF THE SIDE IM-
PACT AIRBAG CONTROL MODULE IS DROPPED AT ANY
TIME, IT MUST BE REPLACED.
Perform AIRBAG VERIFICATION TEST - VER 1.
No → Rewire the Right Side Impact Airbag Control Module connector.
Perform AIRBAG VERIFICATION TEST - VER 1.
4 NOTE: Ensure the battery is fully charged.
With the DRBIIIt, record and erase all DTCs from all modules.
All active codes must be resolved before diagnosing any stored codes.
Maintain a safe distance from all airbags while performing the following steps.
With the DRBIIIt monitor active codes as you work through the system.
NOTE: If equipped with Passenger Airbag On-Off switch, read the DTC’s in
all switch positions.
Wiggle the wiring harness and connectors of the appropriate airbag system and
rotate the steering wheel from stop to stop.
NOTE: Check connectors - Clean and repair as necessary.
You have just attempted to simulate the condition that initially set the trouble code
message.
The following additional checks may assist you in identifying a possible intermittent
problem:
- Visually inspect related wire harness connectors. Look for broken, bent, pushed out,
spread, corroded, or contaminated terminals.
- Visually inspect therelated harnesses. Look for chafed,pierced, pinched or partially
broken wire.
- Refer to Wiring Diagrams and Technical Service Bulletins that may apply.
Did the DTC become active ?
All
Yes → Select appropriate symptom from Symptom List.
No → No problem found at this time. Erase all codes before returning
vehicle to customer.
24
AIRBAG
CONFIGURATION ERROR — Continued
To Next Page
