TEST ACTION APPLICABILITY
3 NOTE: The DRBIIIt communication with the CAB must be operational for
the result of this test to be valid.
Turn the ignition off.
Remove ABS Valve fuse.
Perform the Key-on Bulb Check.
Does the ABS Indicator remain on after the bulb check?
All
Yes → Test Complete.
No → Replace the Controller Antilock Brake in accordance with the
Service Information.
Perform ABS VERIFICATION TEST - VER 1.
4 NOTE: The following steps will initiate the Instrument Cluster self test.
Turn the ignition off.
Press and hold the odometer reset button.
Turn the ignition to RUN.
Observe the Instrument Cluster indicators.
Release the odometer reset button.
Did the ABS Indicator illuminate during the Instrument Cluster self test?
All
Yes → Replace the Controller Antilock Brake in accordance with the
Service Information.
Perform ABS VERIFICATION TEST - VER 1.
No → Replace the Instrument Cluster in accordance with the Service
Information.
Perform ABS VERIFICATION TEST - VER 1.
15
BRAKES (CAB)
CLUSTER LAMP FAILURE — Continued
