TEST ACTION APPLICABILITY
4 Turn the ignition off.
Disconnect the Compass/Temperature Mirror harness connector.
Measure the voltage between the Fused B(+) circuit and ground.
Is the voltage below 10.5 volts?
All
Yes → Repair the Fused B(+) circuit for an open.
Perform BODY VERIFICATION TEST - VER 1.
No → Go To 5
5 Turn the ignition off.
Disconnect the Compass/Temperature Mirror harness connector.
Turn the ignition on.
Measure the voltage between the Fused Ignition Switch Output circuit and ground.
Is the voltage below 10.5 volts?
All
Yes → Repair the Fused Ignition Switch Output circuit for an open.
Perform BODY VERIFICATION TEST - VER 1.
No → Go To 6
6 Turn the ignition off.
Disconnect the Compass/Temperature Mirror harness connector.
Measure the resistance between ground and the Compass/Temperature Mirror
Ground circuit.
Is the resistance above 5.0 ohms?
All
Yes → Repair the Ground circuit for an open.
Perform BODY VERIFICATION TEST - VER 1.
No → Replace the Compass/Temperature Mirror in accordance with the
Service Information.
Perform BODY VERIFICATION TEST - VER 1.
131
COMPASS/MINI-TRIP COMPUTER
*COMPASS/TEMPERATURE MIRROR INOPERATIVE — Continued
To Next Page
