TEST ACTION APPLICABILITY
4 Turn the ignition off.
Inspect the #11 Fuse in the Fuse Block for LHD vehicles (#12 Fuse for LHD autostick
equipped vehicles); #10 Fuse in the Fuse Block for RHD vehicles (#9 Fuse for RHD
autostick equipped vehicles).
If the fuse is open, replace with proper rated fuse.
Turn the ignition on for one minute.
Turn the ignition off.
Inspect the #11 Fuse in the Fuse Block for LHD vehicles (#12 Fuse for LHD autostick
equipped vehicles); #10 Fuse in the Fuse Block for RHD vehicles (#9 Fuse for RHD
autostick equipped vehicles).
Is the fuse open?
All
Yes → Repair the Fused Ignition Switch Output circuit for a short to
ground.
Perform BODY VERIFICATION TEST - VER 1.
No → Go To 5
5 Turn the ignition off.
Disconnect the Instrument Cluster harness connector.
Turn the ignition on.
Measure the voltage between the Fused Ignition Switch Output circuit (pin 15) and
ground. Forautostick equipped vehicles, also measurethe voltage betweenthe Fused
Ignition Switch Output circuit (pin 9) and ground.
Is the voltage above 10.5 volts?
All
Yes → Go To 6
No → Repair the Fused Ignition Switch Output circuit for an open.
Perform BODY VERIFICATION TEST - VER 1.
6 Turn the ignition off.
Disconnect the Instrument Cluster harness connector.
Measure the resistance between ground and the Instrument Cluster Ground circuit.
Is the resistance below 5.0 ohms?
All
Yes → Replace the Instrument Cluster in accordance with the Service
Information.
Perform BODY VERIFICATION TEST - VER 1.
No → Repair the Instrument Cluster Ground circuit for an open.
Perform BODY VERIFICATION TEST - VER 1.
153
INSTRUMENT CLUSTER
*ALL GAUGES INOPERATIVE — Continued
