TEST ACTION APPLICABILITY
4 NOTE: Ensure that the brake fluid is properly filled to the correct level, and
the Base Brake system operates properly.
Turn the ignition on.
With the DRBIIIt in Inputs/Outputs, read the Brake Fluid Level Switch state.
Disconnect the Brake Fluid Level Switch harness connector.
With the DRBIIIt in Inputs/Outputs, read the Brake Fluid Level Switch state.
Did the DRBIIIt Brake Fluid Level Switch input change states?
All
Yes → Replace the Brake Fluid Level Switch in accordance with the
Service Information.
Perform BODY VERIFICATION TEST - VER 1.
No → Go To 5
5 Turn the ignition off.
Disconnect the Brake Fluid Level Switch harness connector.
Disconnect the PCM (C2 connector for 2.0L vehicles) harness connector.
Measure theresistance between groundand the Red Brake Warning Indicator Driver
circuit.
Is the resistance below 10,000 ohms (should be infinite)?
All
Yes → Repair the Red Brake Warning Indicator Driver circuit for a short
to ground (between the Brake Fluid Level Switch and the Instru-
ment Cluster).
Perform BODY VERIFICATION TEST - VER 1.
No → Test Complete.
157
INSTRUMENT CLUSTER
*BRAKE WARNING INDICATOR ALWAYS ON — Continued
To Next Page
