TEST ACTION APPLICABILITY
4 Turn the ignition off.
Remove the Instrument Cluster.
Remove the Low Oil Pressure indicator LED.
Using a DVOM, select 9Diode Mode9, and attach the leads across the LED.
NOTE: Ensure that the RED lead is on the (+( of the LED.
Did the LED illuminate?
All
Yes → Replace the Instrument Cluster in accordance with the Service
Information.
Perform BODY VERIFICATION TEST - VER 1.
No → Replace the Low Oil Pressure Indicator LED in accordance with
the Service Information.
Perform BODY VERIFICATION TEST - VER 1.
168
INSTRUMENT CLUSTER
*LOW OIL PRESSURE INDICATOR INOPERATIVE — Continued
To Next Page
