TEST ACTION APPLICABILITY
3 NOTE: This test is for an EXPORT vehicle only. If this is a DOMESTIC
vehicle, answer YES to the question and continue.
Turn the ignition off.
Disconnect the Remote Keyless Entry module connector.
Remove the passenger door inner trim panel.
Disconnect the Cylinder Lock Switch connector.
Measure the resistance between ground and the passenger Door Switch Mux circuit
(cavity 11).
Is the resistance below 8000.0 ohms?
All
Yes → Go To 4
No → Replace the Cylinder Lock Switch.
Perform BODY VERIFICATION TEST - VER 1.
4 Turn the ignition off.
Disconnect the Door Lock Switch connector.
Disconnect the Remote Keyless Entry module connector.
Measure the resistance between ground and the passenger Door Switch Mux circuit
(cavity 11).
Is the resistance below 8000.0 ohms?
All
Yes → Repair the passenger Door Switch Mux circuit for a short to
ground.
Perform BODY VERIFICATION TEST - VER 1.
No → Replace the Door Lock Switch.
Perform BODY VERIFICATION TEST - VER 1.
191
POWER DOOR LOCKS/RKE
PASSENGER DOOR SWITCH FAILURE — Continued
