TEST ACTION APPLICABILITY
4 Disconnect the Dome Lamp/Intrusion Sensor connector.
Disconnect the Remote Keyless Entry Module connector.
Measure the resistance of the Intrusion Sensor Signal circuit between the sensor
connector and the RKE module connector.
Is the resistance below 5.0 ohms?
All
Yes → Go To 5
No → Repair the Intrusion Sensor Signal circuit for an open.
Perform VTSS VERIFICATION TEST - 1A.
5 Turn the ignition and all the lights off.
Disconnect the Dome Lamp/Intrusion Sensor connector.
Disconnect the Remote Keyless Entry Module Connector.
Measure the resistance of the Intrusion Sensor Signal circuit to ground.
Is the resistance below 1000.0 ohms?
All
Yes → Repair the Intrusion Sensor Signal circuit for a short to ground.
Perform VTSS VERIFICATION TEST - 1A.
No → Go To 6
6 Disconnect the Dome Lamp/Intrusion Sensor connector.
Backprobe a voltmeter lead to the Intrusion Sensor Signal circuit in the sensor
connector and the other lead to ground.
Reconnect the Intrusion Sensor Signal connector.
Wave your hand around the Intrusion Sensor and observe the voltmeter.
Is the voltage between 3.0 and 6.0 volts?
All
Yes → Replace the Remote Keyless Entry Module in accordance with the
Service Information.
Perform VTSS VERIFICATION TEST - 1A.
No → Replace the Intrusion Sensor in accordance with the Service
Information.
Perform VTSS VERIFICATION TEST - 1A.
221
VEHICLE THEFT/SECURITY
*INTRUSION SENSOR FAILS TO TRIP VTSS (EXPORT ONLY) — Continued
To Next Page
