TEST ACTION APPLICABILITY
6 Disconnect the Remote Keyless Entry Module connector.
Measure the resistance of the Decklid Security Switch Sense circuit to ground.
Is the resistance below 10.0 ohms?
All
Yes → Replace the Remote Keyless Entry Module.
Perform VTSS VERIFICATION TEST - 1A.
No → Go To 7
7 Disconnect the Decklid Security Switch connector (behind decklid lock cylinder).
Using a 12-volt Test Light connected to 12-volts, test the Ground circuit for
continuity.
Does the light illuminate?
All
Yes → Go To 8
No → Repair the Decklid Security Switch Ground circuit for an open.
Perform VTSS VERIFICATION TEST - 1A.
8 Turn the ignition off.
Disconnect the Remote Keyless Entry Module connector.
Disconnect the Decklid Security Switch connector (behind decklid lock cylinder).
Connect a jumper wire between the Decklid Security Switch Sense circuit and
ground.
Measure the resistance of the Decklid Security Switch Sense circuit in the RKE
module connector.
Is the resistance below 5.0 ohms?
All
Yes → Replace the Decklid Security Switch.
Perform VTSS VERIFICATION TEST - 1A.
No → Repair the Decklid Security Switch Sense circuit for an open.
Perform VTSS VERIFICATION TEST - 1A.
232
VEHICLE THEFT/SECURITY
*VTSS INDICATOR STAYS ON STEADY DURING ARMING — Continued
To Next Page
