TEST ACTION APPLICABILITY
1 Turn the ignition on.
Ensure the battery is fully charged.
WARNING: IF THE MODULE IS DROPPED AT ANY TIME, IT MUST BE
REPLACED. FAILURE TO TAKE THE PROPER PRECAUTIONS COULD
RESULT IN ACCIDENTAL AIRBAG DEPLOYMENT AND PERSONAL IN-
JURY OR DEATH.
NOTE: For the purpose of this test, the AECM and ORC modules will be
referred to as an ACM.
From the list below, select the appropriate module reporting this diagnostic trouble
code.
SELECT ONE:
All
ACM - ACTIVE or STORED DTC
Replace the Airbag Control Module in accordance with Service
Instructions.
Perform AIRBAG VERIFICATION TEST - VER 1.
LEFT SIACM - ACTIVE or STORED DTC
WARNING: MAKE SURE THE BATTERY IS DISCONNECTED,
THEN WAIT TWO MINUTES BEFORE PROCEEDING. Replace
the Left Side Impact Airbag Control Module in accordance with
Service Instructions.
Perform AIRBAG VERIFICATION TEST - VER 1.
RIGHT SIACM - ACTIVE or STORED DTC
WARNING: MAKE SURE THE BATTERY IS DISCONNECTED,
THEN WAIT TWO MINUTES BEFORE PROCEEDING. Replace
the Right Side Impact Airbag Control Module in accordance with
Service information.
Perform AIRBAG VERIFICATION TEST - VER 1.
NOTE: When reconnecting Airbag system components, the ignition must be
turned off and the battery must be disconnected.
18
AIRBAG
ACCELEROMETER 1 — Continued
To Next Page
