TEST ACTION APPLICABILITY
4 Turn the ignition off.
Disconnect the IAT Sensor harness connector.
Disconnect the PCM harness connector.
Measure the resistance between the (K21) IAT Sensor Signal circuit and the (K4)
Sensor ground circuit in the IAT Sensor harness connector.
Is the resistance below 100 ohms?
All
Yes → Repair the (K167) Sensor ground shorted to the (K21) IAT Signal
circuit.
Perform POWERTRAIN VERIFICATION TEST VER-5-NGC.
No → Go To 5
5 NOTE: Before continuing, check the PCM harness connector terminals for
corrosion, damage, or terminal push out. Repair as necessary.
If there are no possible causes remaining, view repair.
All
Repair
Replace and program the Powertrain Control Module in accor-
dance with the Service Information.
Perform POWERTRAIN VERIFICATION TEST VER-5-NGC.
65
DRIVEABILITY - NGC
P0112-INTAKE AIR TEMPERATURE SENSOR LOW — Continued
