TEST ACTION APPLICABILITY
3 Turn the ignition off.
Disconnect the MAP Sensor harness connector.
Ignition on, engine not running.
Measure the voltage of the (K7) 5 Volt Supply circuit in the MAP Sensor harness
connector.
Is the voltage between 4.5 to 5.2 volts?
All
Yes → Go To 4
No → Go To 8
4 Turn the ignition off.
Disconnect the MAP Sensor harness connector.
Ignition on, engine not running.
With the DRBIIIt, monitor the MAP Sensor voltage.
Is the voltage above 2.2 volts?
All
Yes → Replace the MAP Sensor.
Perform POWERTRAIN VERIFICATION TEST VER-5-NGC.
No → Go To 5
5 Turn the ignition off.
Disconnect the MAP Sensor harness connector.
Disconnect the PCM harness connector.
CAUTION: DO NOT PROBE THE PCM HARNESS CONNECTORS. PROBING
THE PCM HARNESS CONNECTORS WILL DAMAGE THE PCM TERMI-
NALS RESULTING IN POOR TERMINAL TO PIN CONNECTION. INSTALL
MILLER SPECIAL TOOL #8815 TO PERFORM DIAGNOSIS.
Measure the resistance of the (K1) MAP Signal circuit from the MAP Sensor harness
connector to the appropriate terminal of special tool #8815.
Is the resistance below 5.0 ohms?
All
Yes → Go To 6
No → Repair the open in the (K1) MAP Signal circuit.
Perform POWERTRAIN VERIFICATION TEST VER-5-NGC.
6 Turn the ignition off.
Disconnect the MAP Sensor harness connector.
Disconnect the PCM harness connector.
Measure the resistance between ground and the (K1) MAP Signal circuit at the MAP
Sensor harness connector.
Is the resistance below 100 ohms?
All
Yes → Repair the short to ground in the (K1) MAP Signal circuit.
Perform POWERTRAIN VERIFICATION TEST VER-5-NGC.
No → Go To 7
7 NOTE: Before continuing, check the PCM harness connector terminals for
corrosion, damage, or terminal push out. Repair as necessary.
If there are no possible causes remaining, view repair.
All
Repair
Replace and program the Powertrain Control Module in accor-
dance with the Service Information.
Perform POWERTRAIN VERIFICATION TEST VER-5-NGC.
89
DRIVEABILITY - NGC
P0129-BAROMETRIC PRESSURE OUT-OF-RANGE — Continued
To Next Page
