TEST ACTION APPLICABILITY
3 WARNING: TURN THE IGNITION OFF, DISCONNECT THE BATTERY AND
WAIT TWO MINUTES BEFORE PROCEEDING.
If there are no possible causes remaining, view repair.
All
Repair
Replace the Airbag Control Module in accordance with Service
Instructions. WARNING: IF THE AIRBAG CONTROL MODULE
IS DROPPED AT ANY TIME, IT MUST BE REPLACED.
Perform AIRBAG VERIFICATION TEST - VER 1.
4 NOTE: Ensure the battery is fully charged.
With the DRBIIIt, record and erase all DTCs from all modules.
All active codes must be resolved before diagnosing any stored codes.
Maintain a safe distance from all airbags while performing the following steps.
With the DRBIIIt monitor active codes as you work through the system.
NOTE: If equipped with Passenger Airbag On-Off switch, read the DTC’s in
all switch positions.
Wiggle the wiring harness and connectors of the appropriate airbag system and
rotate the steering wheel from stop to stop.
NOTE: Check connectors - Clean and repair as necessary.
You have just attempted to simulate the condition that initially set the trouble code
message.
The following additional checks may assist you in identifying a possible intermittent
problem:
- Visually inspect related wire harness connectors. Look for broken, bent, pushed out,
spread, corroded, or contaminated terminals.
- Visually inspect therelated harnesses. Look for chafed,pierced, pinched or partially
broken wire.
- Refer to Wiring Diagrams and Technical Service Bulletins that may apply.
Did the DTC become active ?
All
Yes → Select appropriate symptom from Symptom List.
No → No problem found at this time. Erase all codes before returning
vehicle to customer.
38
AIRBAG
INTERROGATE LEFT SIACM — Continued
