TEST ACTION APPLICABILITY
10 Turn the ignition off.
Disconnect the CKP Sensor connector.
Ignition on, engine not running.
Measure the voltage on the (K24) CKP Signal circuit.
Wiggle the related wire harness while taking this measurement.
Does the voltage ever increase above 5.5 volts?
All
Yes → Repair the short to B+ voltage in the (K24) CKP Signal circuit.
Perform POWERTRAIN VERIFICATION TEST VER-5-NGC.
No → Go To 11
11 Turn the ignition off.
Disconnect the PCM harness connector.
Disconnect the CKP Sensor harness connector.
Measure the resistance between the (K7) 5 Volt Supply circuit and the (K24) CKP
signal circuit at the CKP Sensor harness connector.
Wiggle the related wire harness while taking this measurement.
Is the resistance below 5.0 ohms?
All
Yes → Repair the short to the (K7) 5 Volt Supply circuit in the (K24)CKP
Signal circuit.
Perform POWERTRAIN VERIFICATION TEST VER-5-NGC.
No → Go To 12
12 NOTE: Before continuing, check the PCM harness connector terminals for
corrosion, damage, or terminal push out. Repair as necessary.
If there are no possible causes remaining, review repair.
All
Repair
Replace and program the Powertrain Control Module in accor-
dance with the Service Information.
Perform POWERTRAIN VERIFICATION TEST VER-5-NGC.
143
DRIVEABILITY - NGC
P0339-CRANKSHAFT POSITION SENSOR INTERMITTENT — Continued
To Next Page
