TEST ACTION APPLICABILITY
3 Turn the ignition off.
Disconnect the Speed Control On/Off Switch harness connector.
Disconnect the Speed Control Resume/Accel Switch harness connector.
Disconnect the PCM harness connector.
Measure the voltage of the (V37) S/C Switch Signal circuit at the Speed Control
harness connector.
Is the is the voltage above 5.0 volts?
All
Yes → Repair the (V37) S/C Switch Signal circuit shorted to the battery
voltage.
Perform POWERTRAIN VERIFICATION TEST VER-4-NGC.
No → Go To 4
4 NOTE: The measurement must be taken from both Speed Control Switch
harness connector.
Turn the ignition off.
Disconnect the Speed Control On/Off Switch harness connector.
Disconnect the Speed Control Resume/Accel Switch harness connector.
Disconnect the PCM harness connector.
CAUTION: DO NOT PROBE THE PCM HARNESS CONNECTORS. PROBING
THE PCM HARNESS CONNECTORS WILL DAMAGE THE PCM TERMI-
NALS RESULTING IN POOR TERMINAL TO PIN CONNECTION. INSTALL
MILLER SPECIAL TOOL #8815 TO PERFORM DIAGNOSIS.
Measure the resistance of the (K4) Sensor Ground circuit from the Speed Control
harness connector to the appropriate terminal of special tool #8815.
Is the resistance below 5.0 ohms for both measurement?
All
Yes → NOTE: Before continuing, check the PCM harness connector
terminals for corrosion, damage or terminal push out. Repair as
necessary. Replace and program the Powertrain Control Module
in accordance with the Service Information.
Perform POWERTRAIN VERIFICATION TEST VER-4-NGC.
No → Repair the (K4) Sensor Ground circuit for an open.
Perform POWERTRAIN VERIFICATION TEST VER-4-NGC.
217
DRIVEABILITY - NGC
P0581-SPEED CONTROL SWITCH #1 HIGH — Continued
