Page #749 background imageLoading...
Page #749 background image
TEST ACTION APPLICABILITY
5 Note: Ensure there is PCI Bus communication with other modules on the
vehicle before proceeding. If not, refer to the symptom list from the menu
and repair as necessary.
Disconnect the PCM harness connectors.
CAUTION: DO NOT PROBE THE PCM HARNESS CONNECTORS. PROBING
THE PCM HARNESS CONNECTORS WILL DAMAGE THE PCM TERMI-
NALS RESULTING IN POOR TERMINAL TO PIN CONNECTION. INSTALL
MILLER SPECIAL TOOL #8815 TO PERFORM DIAGNOSIS.
Use Scope input cable CH7058, Cable to Probe adapter CH7062, and the red and
black test probes.
Connect the scope input cable to the channel one connector on the DRB. Attach the
red and black leads and the cable to probe adapter to the scope input cable.
With the DRBIIIt select Pep Module Tools.
Select lab scope.
Select Live Data.
Select 12 volt square wave.
Press F2 for Scope.
Press F2 and use the down arrow to set voltage range to 20 volts. Set Probe to x10.
Press F2 again when complete.
Connect the Black lead to the chassis ground. Connect the Red lead to the PCI Bus
circuit in the appropriate terminal of special tool #8815.
Turn the ignition on.
Observe the voltage display on the DRB Lab Scope.
Does the voltage pulse from 0 to approximately 7.5 volts?
All
Yes → Replace and program the Powertrain Control Module in accor-
dance with the service information. WITH THE DRBIIIt PER-
FORM QUICK LEARN AND REPROGRAM PINION FACTOR.
Perform 41TE (NGC) TRANSMISSION VERIFICATION TEST -
VER 1.
No → Go To 6
6 Turn the ignition off.
Disconnect the PCM harness connectors.
CAUTION: DO NOT PROBE THE PCM HARNESS CONNECTORS. PROBING
THE PCM HARNESS CONNECTORS WILL DAMAGE THE PCM TERMI-
NALS RESULTING IN POOR TERMINAL TO PIN CONNECTION. INSTALL
MILLER SPECIAL TOOL #8815 TO PERFORM DIAGNOSIS.
Disconnect the BCM C3 harness connector.
Measure the resistance of the PCI Bus circuit from the BCM C3 harness connector to
the appropriate terminal of special tool #8815.
Is the resistance below 5.0 ohms?
All
Yes → Replace the Body Control Module in accordance with the service
information.
Perform 41TE (NGC) TRANSMISSION VERIFICATION TEST -
VER 1.
No → Repair the PCI Bus circuit for an open.
Perform 41TE (NGC) TRANSMISSION VERIFICATION TEST -
VER 1.
28
COMMUNICATION
*NO RESPONSE FROM TRANSMISSION CONTROL MODULE — Continued
