TEST ACTION APPLICABILITY
2 WARNING: TO AVOID PERSONAL INJURY OR DEATH, TURN THE IGNI-
TION OFF, DISCONNECT THE BATTERY AND WAIT TWO MINUTES BE-
FORE PROCEEDING.
WARNING: DO NOT PLACE AN INTACT UNDEPLOYED AIRBAG FACE
DOWN ON A HARD SURFACE, THEAIRBAG WILL PROPEL INTO THEAIR
IF ACCIDENTALLY DEPLOYED, AND COULD RESULT IN SERIOUS OR
FATAL INJURY.
Disconnect the Passenger Airbag connector.
NOTE: Check connectors - Clean and repair as necessary.
Connect the appropriate Load Tool to the Passenger Airbag connector.
WARNING: TO AVOID PERSONAL INJURY OR DEATH, TURN THE IGNI-
TION ON, THEN RECONNECT THE BATTERY.
With the DRBIIIt, read the active Airbag DTCs.
Does the DRBIIIt show PASSENGER SQUIB 1 CIRCUIT SHORT TO GROUND?
All
Yes → Go To 3
No → Replace the Passenger Airbag in accordance with the Service
Information.
Perform AIRBAG VERIFICATION TEST - VER 1.
3 WARNING: TO AVOID PERSONAL INJURY OR DEATH, TURN THE IGNI-
TION OFF, DISCONNECT THE BATTERY AND WAIT TWO MINUTES BE-
FORE PROCEEDING.
Disconnect the Airbag Control Module connector
NOTE: Check connectors - Clean repair as necessary.
Connect the appropriate Load Tool adaptor to the Airbag Control Module connector.
Disconnect the Load Tool from the Passenger Airbag connector.
Measure the resistance of the Passenger Squib 1 Line 1 or Line 2 circuit between the
Passenger Airbag Module Connector and ground.
Is the resistance below 10K ohms on either circuit?
All
Yes → Repair Passenger Squib 1 Line 1 and Line 2 circuits for a short to
ground.
Perform AIRBAG VERIFICATION TEST - VER 1.
No → Go To 4
4 WARNING: TO AVOID PERSONAL INJURY OR DEATH, TURN THE IGNI-
TION OFF, DISCONNECT THE BATTERY AND WAIT TWO MINUTES BE-
FORE PROCEEDING.
WARNING: IF THE AIRBAG CONTROL MODULE IS DROPPED AT ANY
TIME, IT MUST BE REPLACED. FAILURE TO TAKE THE PROPER PRE-
CAUTIONS COULD RESULT IN ACCIDENTAL AIRBAG DEPLOYMENT
AND PERSONAL INJURY OR DEATH.
If there are no possible causes remaining, view repair.
All
Repair
Replace the Airbag Control Module in accordance with Service
Instructions.
Perform AIRBAG VERIFICATION TEST - VER 1.
68
AIRBAG
PASSENGER SQUIB 1 SHORT TO GROUND — Continued
