TEST ACTION APPLICABILITY
4 NOTE: Ensure the battery is fully charged.
With the DRBIIIt, record and erase all DTCs from all modules.
All active codes must be resolved before diagnosing any stored codes.
Maintain a safe distance from all airbags while performing the following steps.
With the DRBIIIt monitor active codes as you work through the system.
NOTE: If equipped with Passenger Airbag On-Off switch, read the DTC’s in
all switch positions.
Wiggle the wiring harness and connectors of the appropriate airbag system and
rotate the steering wheel from stop to stop.
NOTE: Check connectors - Clean and repair as necessary.
You have just attempted to simulate the condition that initially set the trouble code
message.
The following additional checks may assist you in identifying a possible intermittent
problem:
- Visually inspect related wire harness connectors. Look for broken, bent, pushed out,
spread, corroded, or contaminated terminals.
- Visually inspect therelated harnesses. Look for chafed,pierced, pinched or partially
broken wire.
- Refer to Wiring Diagrams and Technical Service Bulletins that may apply.
Did the DTC become active ?
All
Yes → Select appropriate symptom from Symptom List.
No → No problem found at this time. Erase all codes before returning
vehicle to customer.
72
AIRBAG
SEAT SQUIB CIRCUIT OPEN — Continued
