TEST ACTION APPLICABILITY
7 Turn the ignition off to the lock position.
Disconnect the PCM harness connector.
Disconnect the Transmission Solenoid/Pressure Switch Assembly harness connector.
Note: Check connectors - Clean/repair as necessary.
CAUTION: DO NOT PROBE THE PCM HARNESS CONNECTORS. PROBING
THE PCM HARNESS CONNECTORS WILL DAMAGE THE PCM TERMI-
NALS RESULTING IN POOR TERMINAL TO PIN CONNECTION. INSTALL
MILLER SPECIAL TOOL #8815 TO PERFORM DIAGNOSIS.
Measure the resistance between ground and the 2/4 Solenoid Control circuit.
Is the resistance below 5.0 ohms?
All
Yes → Repair the 2/4 Solenoid Control circuit for a short to ground.
Perform 41TE (NGC) TRANSMISSION VERIFICATION TEST -
VER 1.
No → Go To 8
8 Turn the ignition off to the lock position.
Disconnect the PCM harness connector.
Disconnect the Transmission Solenoid/Pressure Switch Assembly harness connector.
Remove the Transmission Control Relay.
Note: Check connectors - Clean/repair as necessary.
Connect a jumper wire between the FusedB+ circuit and Transmission Control Relay
Output circuit in the Transmission Control Relay connector.
Ignition on, engine not running.
CAUTION: DO NOT PROBE THE PCM HARNESS CONNECTORS. PROBING
THE PCM HARNESS CONNECTORS WILL DAMAGE THE PCM TERMI-
NALS RESULTING IN POOR TERMINAL TO PIN CONNECTION. INSTALL
MILLER SPECIAL TOOL #8815 TO PERFORM DIAGNOSIS.
Measure the voltage of the 2/4 Solenoid Control circuit.
Is the voltage above 0.5 volts?
All
Yes → Repair the 2/4 Solenoid Control circuit for a short to voltage.
Perform 41TE (NGC) TRANSMISSION VERIFICATION TEST -
VER 1.
No → Go To 9
9 Turn the ignition off to the lock position.
Disconnect the Transmission Solenoid/Pressure Switch Assembly harness connector.
Remove the Transmission Control Relay.
Note: Check connectors - Clean/repair as necessary.
Connect a jumper wire between the FusedB+ circuit and Transmission Control Relay
Output circuit in the Transmission Control Relay connector.
Using a 12-volt test light connected to ground, check the Transmission Control Relay
Output circuit in the Solenoid/Pressure Switch Assembly harness connector.
NOTE: The test light must illuminate brightly. Compare the brightness to
that of a direct connection to the battery.
Does the test light illuminate brightly?
All
Yes → Go To 10
No → Repair the Transmission Control Relay Output circuit for an
open. If the fuse is open make sure to check for a short to ground.
Perform 41TE (NGC) TRANSMISSION VERIFICATION TEST -
VER 1.
93
TRANSMISSION - NGC
P0755-2/4 SOLENOID CIRCUIT — Continued
