TEST ACTION APPLICABILITY
6 Turn the ignition off to the lock position.
Disconnect the PCM harness connector.
Note: Check connectors - Clean/repair as necessary.
CAUTION: DO NOT PROBE THE PCM HARNESS CONNECTORS. PROBING
THE PCM HARNESS CONNECTORS WILL DAMAGE THE PCM TERMI-
NALS RESULTING IN POOR TERMINAL TO PIN CONNECTION. INSTALL
MILLER SPECIAL TOOL #8815 TO PERFORM DIAGNOSIS.
Using a 12-volt test light connected to 12-volts, check the Ground circuits in the
appropriate terminal of special tool #8815.
NOTE: The test light must illuminate brightly. Compare the brightness to
that of a direct connection to the battery.
Does the test light illuminate brightly for all the ground circuits?
All
Yes → Go To 7
No → Repair the Ground circuits for an open.
Perform 41TE (NGC) TRANSMISSION VERIFICATION TEST -
VER 1.
7 The conditions necessary to set the DTC are not present at this time.
Using the schematics as a guide, inspect the wiring and connectors specific to this
circuit.
Wiggle the wires while checking for shorted and open circuits.
With the DRBIIIt, check the EATX EVENT DATA to help identify the conditions in
which the DTC was set.
Were there any problems found?
All
Yes → Repair as necessary.
Perform 41TE (NGC) TRANSMISSION VERIFICATION TEST -
VER 1.
No → Test Complete.
150
TRANSMISSION - NGC
P1684-BATTERY WAS DISCONNECTED — Continued
