Page #895 background image
TEST ACTION APPLICABILITY
4 Turn the ignition off to the lock position.
Disconnect the PCM harness connector.
Disconnect the AutoStickt Switch harness connector.
Note: Check connectors - Clean/repair as necessary.
CAUTION: DO NOT PROBE THE PCM HARNESS CONNECTORS. PROBING
THE PCM HARNESS CONNECTORS WILL DAMAGE THE PCM TERMI-
NALS RESULTING IN POOR TERMINAL TO PIN CONNECTION. INSTALL
MILLER SPECIAL TOOL #8815 TO PERFORM DIAGNOSIS.
Measure the resistance of the Downshift Sense circuit between the Pinout Box and
the AutoStickt Switch harness connector.
Is the resistance above 5.0 ohms?
All
Yes → Repair the AutoStickt Downshift Sense circuit for an open.
No → Go To 5
5 Ignition on, engine not running.
With the DRBIIIt monitor the AutoStickt Switch status.
Firmly apply the brake and shift into AutoStickt.
Push the shift lever to the right several times to actuate the AutoStickt Upshift
Switch and then to the leftseveral times to actuate theAutoStickt Downshift Switch.
Do both AutoStickt Upshift and Downshift Switch states toggle?
All
Yes → Test Complete.
No → Replace the Powertrain Control Module per the Service Informa-
tion. WITH THE DRBIIIt PERFORM QUICK LEARN AND
REPROGRAM PINION FACTOR.
174
TRANSMISSION - NGC
*NO MANUAL AUTOSTICK OPERATION — Continued
