DURKOPP ADLER 867 Durkopp Adler

Setup
Operating Instructions 867 - 04.0 - 03/2018 103
7.6 Setting the working height
The working height is continuously adjustable between 750 and
900 mm (clearance between the floor and upper edge of the
tabletop).
Fig. 56: Setting the working height
To set the working height:
1. Loosen the screws (1) on the stand bars.
2. Set the tabletop to the desired height.
WARNING
Risk of crushing from moving parts.
The tabletop can sink under its own weight when
the screws on the stand bars are loosened.
Crushing possible.
Ensure that your hands are not jammed when
loosening the screws.
CAUTION
Risk of musculoskeletal damage from
incorrect setting!
The operator can sustain musculoskeletal damage
if failing to comply with the ergonomic requirements.
Adjust the working height to the body height of the
person who will operate the machine.
(1) - Screw
①

DURKOPP ADLER 867 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	12 mm
Needle System	134-35
Needle Thread Tension	Adjustable
Lubrication	Automatic
Type	Industrial Sewing Machine
Max Sewing Speed	3000 stitches per minute
Presser Foot Lift	20 mm
Power Requirements	230V/50Hz
