DURKOPP ADLER 867 Durkopp Adler

Setup
104 Operating Instructions 867 - 04.0 - 03/2018
Important: Pull out or push in the tabletop evenly at both
sides to prevent it from jamming.
3. Tighten the screws (1) on the stand bars.
7.7 Assembling the control
Depending on the subclass, the following controls are available:
Machine type Subclass: 867- Control
Short arm 19020
19040
39240
DAC eco or
DAC classic
Long arm 190020-70
190040-70
290020-70
290040-70
Machines with
integrated motor
190142-M
190322-M
190342-M
DAC classic
Short arm 392342
393342
394342
190122
190142
160122
260122
190145
190125
190146
190322
190342
190445
190425
29040
29020
290122
290142
Efka DC 1550/
DA 321G

DURKOPP ADLER 867 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	12 mm
Needle System	134-35
Needle Thread Tension	Adjustable
Lubrication	Automatic
Type	Industrial Sewing Machine
Max Sewing Speed	3000 stitches per minute
Presser Foot Lift	20 mm
Power Requirements	230V/50Hz
