DURKOPP ADLER 867 Durkopp Adler

Operation
52 Operating Instructions 867 - 04.0 - 03/2018
To lift the sewing feet mechanically using the knee lever (1):
1. Use your right knee to push the knee lever (1) to the right.
 The sewing feet remain open while the knee lever is pushed
to the right.
4.10.2 Electropneumatic lifting with the pedal
Fig. 26: Electropneumatic lifting with the pedal
To lift the sewing feet electropneumatically using the pedal:
1. Press the pedal (1) halfway back.
 The machine stops and lifts the sewing feet.
The sewing feet remain up as long as the pedal is pressed
halfway back.
or
1. Press the pedal (1) fully back.
 The thread cutter is activated, and the sewing feet are raised.
(1) - Pedal
①

DURKOPP ADLER 867 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	12 mm
Needle System	134-35
Needle Thread Tension	Adjustable
Lubrication	Automatic
Type	Industrial Sewing Machine
Max Sewing Speed	3000 stitches per minute
Presser Foot Lift	20 mm
Power Requirements	230V/50Hz
