DURKOPP ADLER 867 Durkopp Adler

Operation
72 Operating Instructions 867 - 04.0 - 03/2018
4.20 Sewing
Use the pedal to start and control the sewing process.
Fig. 40: Sewing
WARNING
Risk of injury from moving, cutting and sharp
parts!
Crushing, cutting and punctures are possible.
Guide the material so that your hands do not slip
under the needle.
Do not press the pedal when you fingers are in
the area of the needle tip.
NOTICE
Property damage may occur!
Remnants of fabric and thread entering the sewing area can
result in damage or defects on the machine.
Immediately remove any contamination during the sewing
process.
Clean the machine daily ( p. 86).
(1) - Pedal position -2
(Sew end bartack and
cut off thread)
(2) - Pedal position -1
(Lift the sewing feet)
(3) - Pedal position 0
(Rest position)
(4) - Pedal position +1
(Sew forward)
④
③
②
①

DURKOPP ADLER 867 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	12 mm
Needle System	134-35
Needle Thread Tension	Adjustable
Lubrication	Automatic
Type	Industrial Sewing Machine
Max Sewing Speed	3000 stitches per minute
Presser Foot Lift	20 mm
Power Requirements	230V/50Hz
